Features
Applications
Maximum rating (Ta : 25 ℃)
| Characteristics | Symbol | Min. | Typical | Max. | Unit |
| DC Forward Current 1 | I F | --- | --- | 100 | mA |
| Pulse Current 2 | I IFP | --- | --- | 150 | mA |
| Forward Voltage | VF | 5.0 | --- | 9.0 | V |
| Junction Temperature 3 | Tj | --- | --- | 65 | ℃ |
| Storage Temperature Range | Tsto | -40 | --- | 100 | ℃ |
| Soldering Temperature | Tsol | --- | 245 | ℃ | |
| Thermal Resistance Junction / Solder Point |
Rth | --- | 25 | --- | ℃/W |
| Beam Angle | 2θ1/2 | --- | 30 | --- | Deg |
Notes:
1. For other ambient, limited setting of current will depend on de-rating curves.
2. D=0.01s duty 1/10.
3. When driving at maximum current the Tj must be kept below 65℃
4. Viewing angle(2θ 1/2 ) ± 10°
Relative spectral power distribution
